How does the transducer mount to the pole?
Mounting to our pole uses the transducer manufacturer’s shaft mount bracket (the same as the trolling motor shaft mount) in conjunction with the BD-supplied transducer bushing to create the correct clamping diameter.
Why won’t my pole break away?
The breakaway pole has two “user” positions: the breakaway position and the fixed position (180 degrees apart). The pole position can be adjusted by pulling back on the spring pin and rotating the outer face of the pole clamp.
With the clamp in a vertical (“user”) position, one side of the clamp will have a visible hole, and the other side will not. If the spring pin lines up with the hole, it is locked or fixed. It is in the breakaway position if it is aligned with the side without a hole.
Check out our video on switching between the BreakAway and Fixed positions.
How do I put the breakaway pole in a fixed position?
The breakaway pole has two “user” positions: the breakaway position and the fixed position (180 degrees apart). The pole position can be adjusted by pulling back on the spring pin and rotating the outer face of the pole clamp.
With the clamp in a vertical (“user”) position, one side of the clamp will have a visible hole, and the other side will not. If the spring pin lines up with the side missing the hole, the clamp is in the fixed position.
Check out our video on switching between the BreakAway and Fixed positions.
Can I upgrade my fixed pole to a breakaway pole?
A Breakaway Upgrade Kit is available for purchase. It will allow you to convert your fixed pole to a breakaway pole. It is a complete bolt-on unit that will replace the clamp that holds the pole on the original fixed mount.
Where can I find replacement parts for the transducer poles?
Transducer Pole Parts can be found here.
How does the tension knob work on the pole?
The tension knob is designed to restrict the rotation of the pole in its bushing. The tighter the knob, the harder the pole rotates. The looser the knob, the easier the pole rotates, allowing the user to change the direction of the transducer more easily.
Why is the PVC tubing turning inside the pole?
When the All-Terrain transducer pole (PVC section of the pole) is shipped, the PVC section is slid into the aluminum section to fit into the product box. Upon assembly and before use, the PVC section needs to be extended and aligned with the snap button holes in the aluminum tubing.
Once the PVC’s snap button is located in the hole of the aluminum tubing, it will not be able to rotate. There are four different holes in the aluminum tubing to set the desired length of the PVC portion. It is advised only to stick out as much as necessary.
Why is the transducer spinning on the PVC portion of the All-Terrain?
It is important to use the transducer manufacturer’s shaft-style clamp (made for a trolling motor) when mounting it to a BD transducer pole. BD provides a split transducer bushing (taped on the PVC section of the pole) that must be used when mounting the transducer.
The correct assembly should consist of the transducer clamp around the PVC section and then the manufacturer’s shaft-style clamp around the bushing. Tighten the manufactures clamp adequately. This will secure the transducer from spinning on the PVC.
*Some customers have found it necessary to bolt the shaft-style clamp in place through the PVC section if the product is being used in heavily wooded waters.
